LSA (LSI Storage Authority), MegaRAID Storage Manager, StorCLI (command-line interface), CTRL-R (BIOS configuration utility), HII (UEFI Human Interface Infrastructure)
Host Bus Type
x8 lane PCI Express® 3.0
Internal Ports
4
Data Transfer Rates
Up to 12Gb/s per port
Internal Connectors
1 HD Mini-SAS SFF8643 (Horizontal mount)
Operating Temperature
0°C to 70°C
Operating Voltage (V)
+12V
OS
Extensive support includes Microsoft® Windows® Vista/2008/Server 2003/2000/XP, Linux®, Solaris™ (x86), Netware®, FreeBSD®, VMware® and more. *Visit the downloads page for the most complete list of supported operating systems
Regulatory Certifications
Australia/New Zealand (AS/NZS 3548), Canada (ICES-003), EMC: Class B-US (CFR 47, P15B), Europe (EN55022/EN55024), Japan (V-3/02.04), Safety: EN60950
Warranty
3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba
