CPU
|
CPU Model |
Annapurna Labs Alpine AL-314 |
|
CPU Architecture |
32-bit |
|
CPU Frequency |
Quad Core 1.7 GHz |
|
Hardware Encryption Engine |
|
Memory
|
System Memory |
4 GB DDR3L |
|
Memory Module Pre-installed |
4 GB (4 GB x 1) |
|
Total Memory Slots |
2 |
|
Memory Expandable up to |
8 GB (4 GB x 2) |
|
Notes |
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. |
Storage
|
Drive Bays |
8 |
|
Maximum Drive Bays with Expansion Unit |
18 |
|
Compatible Drive Type* (See all supported drives) |
- 3.5″ SATA HDD
- 2.5″ SATA HDD
- 2.5″ SATA SSD
|
|
Maximum Internal Raw Capacity |
128 TB (16 TB drive x 8) (Capacity may vary by RAID types) |
|
Maximum Raw Capacity with Expansion Units |
288 TB (128 TB + 16 TB drive x 10) (Capacity may vary by RAID types) |
|
Maximum Single Volume Size* |
108 TB |
|
Hot Swappable Drive |
|
|
Notes |
- “Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
- The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit.
- Each internal volume (may consist of multiple drives) is expandable up to 108TB.
|
External Ports
|
RJ-45 1GbE LAN Port |
2 (with Link Aggregation / Failover support) |
|
RJ-45 10GbE LAN Port |
2 (with Link Aggregation / Failover support) |
|
USB 3.0 Port |
2 |
|
eSATA Port |
2 |
File System
|
Internal Drives |
|
|
External Drives |
- EXT4
- EXT3
- FAT
- NTFS
- HFS+
- exFAT*
|
|
Notes |
exFAT Access is purchased separately in Package Center. |
Appearance
|
Size (Height x Width x Depth) |
157 mm x 340 mm x 233 mm |
|
Weight |
5.31 kg |
Others
|
System Fan |
120 mm x 120 mm x 2 pcs |
|
Fan Speed Mode |
|
|
Easy Replacement System Fan |
|
|
Power Recovery |
|
|
Noise Level* |
24.2 dB(A) |
|
Scheduled Power On / Off |
|
|
Wake on LAN / WAN |
|
|
Power Supply Unit / Adapter |
250 W |
|
AC Input Power Voltage |
100 V to 240 V AC |
|
Power Frequency |
50/60 Hz, Single Phase |
|
Power Consumption* |
59.1 W (Access)
26.4 W (HDD Hibernation) |
|
British Thermal Unit |
201.66 BTU/hr (Access)
90.08 BTU/hr (HDD Hibernation) |
|
Notes |
- Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
- Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
Temperature
|
Operating Temperature |
5°C to 40°C (40°F to 104°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
Certification
|
- EAC
- CCC
- RCM
- KC
- FCC
- CE
- BSMI
|
Warranty
|
3-year hardware warranty, extendable to 5-year coverage – EW201 |
|
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt. |
Environment
|
RoHS Compliant |
Packaging Content
|
- Main Unit X 1
- Welcome Note X 1
- Accessory Pack X 1
- AC Power Cord X 1
- RJ-45 LAN Cable X 2
|
Optional Accessories
|
- Surveillance Device License Pack
- RAM1600DDR3-4G DDR3 non-ECC SO-DIMM
- Expansion Unit: DX517 X 2
- VS360HD
- VS960HD
|
