| Lifecycle |
Active |
| Distrib. Inventory |
No |
| Generation |
12 Gb/s |
| External Ports |
8 |
| External Connectors |
2 x4 SFF-8644 |
| Management Software |
LSI Storage Authority (LSA), StorCLI (Command-Line Interface), HII (UEFI Human Interface Infrastructure) |
| Cache Protection |
CacheVault CVPM05 |
| Physical Dimensions |
6.600″ x 2.712″ |
| Host Bus Type |
x8 lane PCI Express 4.0 |
| Cache Memory |
8GB |
| Internal Ports |
8 |
| Data Transfer Rates |
12Gb/s SAS and 16GT/s PCIe Gen4 (NVMe) compliant |
| Devices Supported |
SAS/SATA: 240, NVMe: 24 |
| Internal Connectors |
1 x8 SFF-8654 (SlimSAS) |
| MTBF |
>3,000,000 hours at 40° C |
| Operating Temperature |
0°C to 55°C |
| OS |
Microsoft Windows, VMware vSphere/ESXi, Red Hat Enterprise Linux, SuSE Linux, Ubuntu Linux, Citrix XenServer, CentOS Linux, Debian Linux, Oracle Enterprise Linux, Fedora, FreeBSD |
| Regulatory Certifications |
Australia/New Zealand (AS/NZS CISPR 22), Canada (ICES -003, Class B), Europe (EN55022/EN55024), Japan (VCCI V-3), Korea (RRA no 2013-24 & 25), RoHS compliant, Safety: EN/IEC/UL 60950, Taiwan (CNS 13438), USA (FCC 47 CFR part 15 Subpart B, class B), WEEE |
| Warranty |
3 years, free technical support, advanced replacement option at broadcom.com/support/warranty/internal-raid-hba |
| I/O Processor / SAS Controller |
SAS3916 12Gb/s SAS Tri-Mode RAID-on-Chip (ROC) |
