CPU
|
CPU Model |
Intel Xeon D-1567 |
|
CPU Architecture |
64-bit |
|
CPU Frequency |
12 Core 2.1 (base) / 2.7 (turbo) GHz |
|
Hardware Encryption Engine (AES-NI) |
|
Memory
|
System Memory |
16 GB DDR4 ECC RDIMM |
|
Memory Module Pre-installed |
16 GB (16 GB x 1) |
|
Total Memory Slots |
4 |
|
Memory Expandable up to |
128 GB (32 GB x 4) |
|
Notes |
- Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
- Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
|
Storage
|
Drive Bays |
12 |
|
Maximum Drive Bays with Expansion Unit |
96 (RX1217sas) / 180 (RX2417sas) |
|
Compatible Drive Type* (See all supported drives) |
- 3.5″ SAS HDD
- 2.5″ SAS HDD
- 2.5″ SAS SSD
- 3.5″ SATA HDD
- 2.5″ SATA HDD
- 2.5″ SATA SSD
|
|
Maximum Internal Raw Capacity |
192 TB (16 TB drive x 12) (Capacity may vary by RAID types) |
|
Maximum Raw Capacity with Expansion Units |
1,536 TB (192 TB + 16 TB drive x 84) (Capacity may vary by RAID types) |
|
Maximum Single Volume Size* |
- 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
- 108 TB
|
|
Hot Swappable Drive |
|
|
Notes |
- “Compatible drive type” indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
- The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit.
- Each internal volume (may consist of multiple drives) is expandble up to 108TB (with memory less than 32GB) or 200TB (with memory equal to or greater than 32GB).
|
External Ports
|
RJ-45 1GbE LAN Port |
4 (with Link Aggregation / Failover support) |
|
RJ-45 10GbE LAN Port |
2 (with Link Aggregation / Failover support) |
|
USB 3.0 Port |
2 |
|
Expansion Port |
1 |
PCIe
|
PCIe Expansion |
2 x Gen3 x8 slots (x8 link) |
|
Add-In-Card Support |
PCIe Network Interface Card |
File System
|
Internal Drives |
|
|
External Drives |
- Btrfs
- EXT4
- EXT3
- FAT
- NTFS
- HFS+
- exFAT*
|
|
Notes |
exFAT Access is purchased separately in Package Center. |
Appearance
|
Form Factor (RU) |
2U |
|
Size (Height x Width x Depth) |
88 mm x 482 mm x 724 mm |
|
Weight |
14.5 kg |
|
Rack Installation Support* |
4-post 19″ rack (Synology Rail Kit – RKS1317) |
|
Notes |
The rail kit is sold separately |
Others
|
System Fan |
80 mm x 80 mm x 4 pcs |
|
Fan Speed Mode |
- Full-Speed Mode
- Cool Mode
- Quiet Mode
|
|
Easy Replacement System Fan |
|
|
Power Recovery |
|
|
Noise Level* |
49.8 dB(A) |
|
Scheduled Power On / Off |
|
|
Wake on LAN / WAN |
|
|
Power Supply Unit / Adapter |
500 W |
|
Redundant Power Supply |
|
|
AC Input Power Voltage |
100 V to 240 V AC |
|
Power Frequency |
50/60 Hz, Single Phase |
|
Power Consumption* |
156.23 W (Access)
72.37 W (HDD Hibernation) |
|
British Thermal Unit |
533.08 BTU/hr (Access)
246.94 BTU/hr (HDD Hibernation) |
|
Notes |
- Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
- Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
Temperature
|
Operating Temperature |
0°C to 35°C (32°F to 95°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
Certification
|
- EAC
- VCCI
- CCC
- RCM
- KC
- FCC
- CE
- BSMI
|
Warranty
|
5 Years |
|
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt. |
Environment
|
RoHS Compliant |
Packaging Content
|
- Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 2
- Quick Installation Guide X 1
|
Optional Accessories
|
- D4RD-2666-16G DDR4 ECC RDIMM*
- D4RD-2666-32G DDR4 ECC RDIMM
- Surveillance Device License Pack
- Expansion Unit: RX1217sas X 7
- Expansion Unit: RX2417sas X 7
- Synology Ethernet Adapter E10G17-F2
- Synology Ethernet Adapter E10G18-T1
- Synology Ethernet Adapter E10G18-T2
- Synology Rail Kit Sliding – RKS1317
- VS360HD
- VS960HD
|
|
Notes |
It is required to use D4RD-2666-16G with identical memory modules of the same capacity and frequency. For more information, visit here. |
