Product Type |
SSD Plextor |
Performance |
Sequential Read Speed* |
Up to 3,200 MB/s |
Sequential Write Speed* |
Up to 2,100 MB/s |
Random Read Speed* |
Up to 400,000 IOPS |
Random Write Speed* |
Up to 300,000 IOPS |
Environment and Reliability |
Power Requirement |
DC 12V 1.0A (Max.) at PCIe Slot |
Temperature |
0°C ~ 70°C / 32°F ~ 158°F (Operating) |
Shock |
1500G (Max.) , at 1 msec half-sine |
MTBF |
>1,500,000 Hours |
Endurance (TBW) |
640 |
Warranty |
5 years |
Compatibility |
Operating System Supported |
Microsoft Windows 8.1, 10/ Linux OS |
Agency Approval |
UL, TUV, FCC, CE, BSMI, VCCI, RCM, KCC, EAC, ROHS, WHQL |
Command Set Support |
TRIM, S.M.A.R.T, IO queue, NVMe command |
Interface |
M.2 PCIe Gen 3 x4 with NVM Express |
Firmware Upgrade |
Supported |
Form Factor and Connectors |
Form Factor |
Standardized PCl Express Card with Half-Height/Half-Length |
Power Connector |
DC 12V PCI Express Slot |
Data Connector |
PCI Express Slot |
Dimension and Weight |
Dimension (L/W/H) |
176.33 X 121.04 X 22.39 mm / 6.94 X 4.77 X 0.88 inch |
Weight (Max.) |
200g / 7.05oz |
