Processor
|
|
|
Cache memory
|
|
|
Memory protection
|
ECC
|
|
Memory
|
Type
|
HPE Standard memory DDR4 unbuffered (UDIMM)
|
|
DIMM slots available
|
2
|
|
Standard
|
8GB (1 x 8GB) PC4-2400T DDR4 UDIMM
|
|
Maximum
|
32GB (2 x 16GB) PC4-2400T DDR4 UDIMM
|
NOTE:
-
HPE memory from previous generation servers are not fully compatible with the HPE ProLiant MicroServer Gen10.
-
Only the SKUs with X3421 processor support memory speed up to 2400 MT/s.
-
SKUs with X3216 processor only support up to 1600 MT/s memory speed.
|
|
Network controller
|
Embedded Broadcom BCM5720 dual port Gbe LOM
|
|
Expansion slots
|
|
Expansion Slot
|
Technology
|
Bus Width
|
Connector Width
|
Form Factor
|
Notes
|
|
1
|
PCIe 3.0
|
X8
|
X8
|
Low profile
|
Open-end connector to support up to x16 PCIe card
|
|
2
|
PCIe 3.0
|
X1
|
X4
|
Low profile
|
Open-end connector to support up to x16 PCIe card
|
|
|
Storage controller
|
The Gen10 controller naming framework has been updated to simplify identification as depicted below.
|
Embedded storage controller
|
Marvell 88SE9230 PCIe to SATA 6Gb/s controller
NOTE:
Supports RAID 0/1/10 only. No FBWC support.
|
|
Essential RAID controller
|
HPE Smart Array E208i-p SR Gen10 controller
NOTE:
Supports RAID 0/1/5/10. No FBWC support.
|
|
|
Internal storage devices
|
Optical drive
|
|
|
Hard drives
|
None ship standard
|
|
Solid State Drives (SSD)
|
None ship standard
|
|
Maximum internal storage
|
Non-hot plug SATA
|
16TB (4 x 4TB) 3.5 in SATA
|
|
Interfaces
|
Video
|
-
1 Rear VGA port
-
2 Rear display ports 1.2
|
|
USB 2.0 ports
|
3 total (2 rear, 1 internal)
|
|
USB 3.0 ports
|
4 total (2 rear, 2 front)
|
|
Network RJ-45 (Ethernet) 2
|
|
|
Industry standardcompliance
|
-
ACPI V5.0 compliant
-
PCIe 3.0 compliant
-
PXE support
-
WOL support
-
EMC class B
-
USB 2.0
-
USB 3.0
-
SATA 6 Gb/s
|
|
System fans
|
One (1) non-redundant system fan shipped standard.
|
|
Form factor
|
Ultra micro tower.
|
